Our mosaic mimic panel system offers a vast variety of possibilities for use when it comes to presenting mimic panel diagrams. We offer steel, stainless steel or aluminum material for panel/console. The layout of the mosaic mimic panel diagrams can be designed as follows :
¡@¡@¡@¡@¡@1. curved type
¡@¡@¡@¡@¡@2. fan type
¡@¡@¡@¡@¡@3. polygonal type
¡@¡@¡@¡@¡@4. flat type
¡@¡@¡@¡@¡@5. console type
¡@¡@¡@We would like to mention that curved type is the best choice which enable operator easy access each control point of the panel. We can offer the most advanced curved type display panel with different radius ranging from 5M 6M 7M 8M 9M 10M 11M. Inform us the dimension when ordering.

¡@¡@¡@ Large display boards are installed in free standing structures, made up of prefabricated steel or aluminum frames and assembled at the installation site in an erector set manner. Others are housed in customized cabinets, consoles or wall-mounting enclosure depending on customer's specifications.

Fig.4-1 : Wall mounting mosaic panel in Taipei







Fig.1 : The curved mosaic display board   is composed of 24mm tiles
Fig.2 : Electrical power system board of Taiwan Power Company's Kaosiung Nanpu power station
Fig.3 : Traffic control board of Taiwan Railway Taipei station
Fig.4 : Gate control board of Fei-tuei dam, Taipei

Fig.3 : Tunnels traffic control board of Taiwan Railway
